Porsche 911 2014 Fuse Box Info
Passenger compartment fuse box location:
The fuse boxes are located in the footwell on the driver's side, and on the passenger's side.
Fuse Box Diagram | Layout
Passenger compartment fuse box (Driver's side):
| Fuse/Relay N° | Rating | Functions |
| Fuse panel A | ||
| 1 | 40A | Lower left: Air-conditioning fan, R/L |
| 2 | 40A | Upper left: PSM control unit |
| 3 | 25A | Lower right: Seat adjustment |
| 4 | 40A | Upper right: PASM control unit |
| Fuse panel B | ||
| 1 | 40A | Headlight adjustment for LHD/RHD, Front lid light, Front lid actuator, High beam, FL, Dipped beam, FL, Side marker light, FR, Direction indicator, RL/FL |
| 2 | 15A | Exhaust flap control, Raised brake light, spoiler, Rear lid actuator, Rear fog light, right, Reversing light, left, Brake light, left, Tail light, left, Daytime driving light, FL |
| 3 | 15A | Alarm horn |
| 4 | 15A | Interior lighting, Hall sensors, Orientation light, Number plate light, Rear wiper electronics activation, Heated rear window relay, Central locking LED, Door panels LED, Ambient light, Raised brake light, Rear fog light, left, Brake light, right, Reversing light, right, Daytime driving light, FR, Tail light, right |
| 5 | 20A | Fuel pump relay and control unit |
| 6 | 10A | Filler flap close/open, Electric steering column lock Terminal 30, Washer pump, front/rear |
| 7 | - | Not used |
| 8 | 7.5A | Air conditioning control unit |
| 9 | 10A | Instrument cluster, Steering column, stopwatch |
| 10 | 25A | PCM |
| Fuse panel C | ||
| 1 | 15A | Centre console button panel, Gateway control unit, Diagnostic socket, Ignition lock, Steering column lock, Passenger compartment monitoring sensor, Light switch, Bluetooth phone charger |
| 2 | 40A | Start-relevant loads, Footwell lights, Electric ignition lock anti-removal lock, Direction indicator, FL/FR, Hazard warning light button LED, Electric ignition lock light, Side direction indicators, FR/FL, High beam, FR, Dipped beam, FR, Direction indicator, RR, Side marker light, FL, Heated washer jets |
| 3 | 5A | Vehicle Tracking System control unit |
| 4 | 15A | Horn |
| 5 | 30A | Cabriolet: Convertible-top lock closing mechanism open/closed, Filler flap, Cabriolet: Convertible top storage compartment catch open/close, Rear spoiler control extend/retract |
| 6 | 25A | Power window control unit, FL |
| 7 | 30A | Headlight cleaning system |
| 8 | 25A | PSM control unit |
| 9 | 5A | Alarm siren |
| 10 | - | Not used |
| Fuse panel D | ||
| 1 | 15A | Rear wiper |
| 2 | 5A | HomeLink |
| 3 | 5A | Left headlight |
| 4 | 5A | Gateway/diagnostic socket, Air quality sensor, Headlight control unit, PDC control unit |
| 5 | 5A | PSM control unit |
| 6 | 5A | Steering column switching module, Electronic steering gear, Refrigerant pressure sensor |
| 7 | 5A | Selector lever control unit, Clutch switch sensor |
| 8 | 5A | Right headlight |
| 9 | 5A | Interior mirror |
| 10 | 5A | Seat ventilation, left |
Passenger compartment fuse box (Passenger's side):
| Fuse/Relay N° | Rating | Functions |
| Fuse panel A | ||
| 1 | 40A | Lower left: DC/DC converter, infotainment |
| 2 | 40A | Upper left: DC/DC converter roof console power supply |
| 3 | 40A | Lower right: LHD, fresh-air blower motor, LHD, blower regulator |
| 4 | 25A | Upper right: Right seat control unit, Seat adjustment |
| Fuse panel B | ||
| 1 | 5A | Rain sensor |
| 2 | 25A | Air conditioning control unit |
| 3 | - | Not used |
| 4 | 10A | PDCC control unit |
| 5 | 5A | TPM control unit |
| 6 | 5A | TV tuner |
| 7 |
40A 25A |
Burmester subwoofer amplifier Bose subwoofer amplifier
|
| 8 | - | Not used |
| 9 | 10A | All-wheel control unit |
| 10 | 5A | Not used |
| Fuse panel C | ||
| 1 | - | Not used |
| 2 | 5A | Electric parking brake button |
| 3 | - | Not used |
| 4 | 20A | Cabriolet: Rear power window control unit, RR |
| 5 | 5A | Temperature sensor, Tank leakage diagnosis |
| 6 | 30A | Front wiper motor |
| 7 | 25A | Power window control unit, FR |
| 8 | 25A | Steering column adjustment |
| 9 | 5A | Roof console |
| 10 | 40A/25A | Sound system amplifier |
| Fuse panel D | ||
| 1 | 5A | Airbag control unit |
| 2 | 5A | All-wheel control unit |
| 3 | 7.5A | PDCC control unit |
| 4 | 5A | ACC control unit |
| 5 | 5A | Control unit, seat occupancy detection |
| 6 | 5A | Seat ventilation, right |
| 7 | 5A | DME control unit, PDK, VTS, BCM, rear |
| 8 | 20A | Footwell socket |
| 9 | 20A | Centre console socket, Cigarette lighter |
| 10 | 20A | Socket in glove box |
