Hyundai i30 N 2018 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| 1. MODULE 5 | 7.5A | Electro Chromic Mirror, MTS E-Call Module, Audio, A/V & Navigation Head Unit, A/C Control Module, A/T Shift Lever Indicator, Console Switch RH, DC-DC Converter, Head Lamp LH/RH, Auto Head Lamp Leveling Device Module, Front Seat Warmer Control Module, Driver IMS Module |
| 2. MODULE 3 | 7.5A | Driver/Passenger Door Module, BCM |
| 3. SUNROOF 1 | 20A | Panorama Sunroof |
| 4. TAILGATE | 10A | Tail Gate Relay |
| 5. POWER WINDOW LH |
25A | Power Window LH Relay, Driver/Passenger Safety Window Module, Rear Safety Window Module LH |
| 6. MULTIMEDIA | 15A | Audio, A/V & Navigation Head Unit, DC-DC Converter |
| 7. POWER WINDOW RH |
25A | Power Window RH Relay, Driver/Passenger Safety Window Module, Rear Safety Window Module RH |
| 8. POWER SEAT DRIVER |
25A | Driver Seat Manual Switch, Driver IMS Module |
| 9. POWER SEAT PASSENGER |
25A | Passenger Seat Manual Switch |
| 10. MODULE 4 | 7.5A | Lane Keeping Assist Module, Stop Lamp Switch, BCM, LSD ECU, ECS Unit |
| 11. SMART KEY 2 | 7.5A | Smart Key Control Module, Immobilizer Module |
| 12. SUNROOF 2 | 20A | Panorama Sunroof |
| 13. INTERIOR LAMP |
7.5A | Wireless Charger, Vanity Lamp LH/RH, Room Lamp, Overhead Console Lamp, Personal Lamp LH/RH, Rain Sensor, Ignition Key Ill.& Door Warning Switch, Glove Box Lamp, Luggage Lamp, Rain Sensor |
| 14. MEMORY 2 | 7.5A | MTS E-Call Module |
| 16. MEMORY 1 | 10A | Driver/Passenger Door Module, Driver IMS Module, BCM, A/C Control Module, Instrument Cluster, Auto Light & Photo Sensor, ICM Relay Box (Outside Mirror Folding/Unfolding Relay) |
| 17. E-LSD | 20A | LSD ECU |
| 18. ECS | 15A | ECS Unit |
| 19. MODULE 6 | 7.5A | Smart Key Control Module, BCM |
| 20. MDPS | 7.5A | MDPS Unit, Steering Angle Sensor - MDPS (Motor Driven Power Steering) is the same as EPS (Electric Power Steering) |
| 21. MODULE 1 | 7.5A | Hazard Switch, Center Door Lock Switch, Driver/Passenger Door Module, Driver/Passenger Power Outside Mirror, Driver/Passenger Smart Key Outside Handle, Data Link Connector |
| 22. MODULE 7 | 7.5A | Front Seat Warmer Control Module, ESG Unit, Cooling Fan Motor, Nozzle |
| 23. AIRBAG INDICATOR |
7.5A | Instrument Cluster, Center Door Lock Switch |
| 24. BRAKE SWITCH |
7.5A | Smart Key Control Module, Stop Lamp Switch |
| 25. START | 7.5A | Smart Key Control Module, Engine Room Junction Block (RLY.4) |
| 26. CLUSTER | 7.5A | Instrument Cluster |
| 27. DOOR LOCK | 20A | Door Lock/Unlock Relay, ICM Relay Box (Dead Lock Relay) |
| 30. SEAT HEATER FRONT |
20A | Front Seat Warmer Control Module |
| 31. AIR CONDITIONER 2 |
10A | A/C Control Module, ECM, Blower Motor, Engine Room Junction Block (RLY.10) |
| 32. AIR CONDITIONER 1 |
7.5A | A/C Control Module, Engine Room Junction Block (RLY.10/11) |
| 33. SMART KEY 1 | 15A | Smart Key Control Module, Immobilizer Module |
| 35. AIRBAG | 15A | SRS Control Module |
| 36. IGNITION 1 | 25A | PCB Block (F45/F46/F47) |
| 37. MODULE 2 | 10A | Wireless Charger, MTS E-Call Module, Smart Key Control Module, BCM, Audio, A/V & Navigation Head Unit, DC-DC Converter, Power Outside Mirror Switch, Engine Room Junction Block (RLY.14) |
| 38. WASHER | 15A | Multifunction Switch |
| 39. WIPER | 10A | ECM, BCM |
| 40. REAR WIPER | 15A | Rear Wiper Relay |
| 42. MIRROR HEATED |
10A | Driver/Passenger Power Outside Mirror, A/C Control Module |
| 43.POWER OUTLET |
20A | Rear Power Outlet #2 |
| 45. HEATED STEERING |
15A | BCM |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| RLY.3 | - | PDM #3 (IG1) Relay |
| RLY.4 | - | START Relay |
| RLY.5 | - | E-CVVT Relay |
| RLY.6 | - | PDM #4 (IG2) Relay |
| RLY.7 | - | FUEL PUMP Relay |
| RLY.8 | - | PDM #2 (ACC) Relay |
| RLY.10 | - | BLOWER Relay |
| RLY.11 | - | PTC HEATER #1 Relay |
| RLY.12 | - | REAR DEFOGGER Relay |
| RLY.14 | - | POWER OUTLET Relay |
| 1. MAIN | 180A | Fuse :F27, F29, F30, F33 |
| 2. MDPS 1 | 100A | MDPS Unit - MDPS (Motor Driven Power Steering) is the same as EPS (Electric Power Steering) |
| 3. B+5 | 60A | PCB Block (Fuse :F44, F50, F51, F52, Engine Control Relay) |
| 4. B+2 | 60A | IGPM (Fuse :F30, IPS0, IPS1, IPS2) |
| 5. B+3 | 60A | IGPM (IPS3, IPS4, IPS5, IPS6, IPS7, IPS8) |
| 6. B+4 | 60A | IGPM (Fuse :F3, F4, F5, F7, F8, F9, F12, F17, F18) |
| 8. REAR HEATED |
40A | RLY.12 |
| 9. BLOWER | 40A | RLY.10 |
| 10. IGNITION 1 | 40A | Ignition Switch, Engine Room Junction Block (RLY.3, RLY8) |
| 11. IGNITION 2 | 40A | Ignition Switch, Engine Room Junction Block (RLY.4, RLY.6) |
| 12. COOLING FAN |
80A | Cooling Fan Motor |
| 13. PTC HEATER 1 |
50A | RLY.11 |
| 17. POWER OUTLET 3 |
20A | Rear Power Outlet |
| 18. POWER OUTLET 2 |
20A | Front Power Outlet |
| 21. VACUUM PUMP 1 |
20A | Vacuum Pump |
| 22. FUEL PUMP | 20A | RLY.7 |
| 24. B+1 | 40A | IGPM (Leak Current Autocut Device, Fuse :F21, F24, F27, F33) |
| 27. BURGLAR ALARM HORN |
10A | ICM Relay Box (Burglar Alarm Horn Relay) |
| 29. ABS 1 | 40A | ESP Control Module |
| 30. ABS 2 | 30A | ESP Control Module |
| 31. E-CVVT 3 | 40A | RLY.5 |
| 33. POWER OUTLET 1 | 40A | RLY.14 |
| 34. E-CVVT1 | 10A | ECM |
| 35. E-CVVT 2 | 20A | ECM |
| Battery Fuse Panel | ||
| AMS | 10A | AMS |
